CDI ELECTRONICS

ELECTRICAL PARTS
88 HP thru 100 HP

Flywheel Magnets Came Off Your V4 or V6 35-Amp Charging System (90° Motors Only) ??
Don't buy a new flywheel; Get magnet kits HERE

Rapair/CDI Electronics has grown to be THE source for quality electronic ignition parts for all makes of US outboard motors.
Now supplying some of the OEM manufacturers with selected components. Some components of the outboard electrical system are not available from CDI,
in this case we have listed the in this case I have listed FACTORY or SIERRA parts.

Engine wiring harnesses are also available for most motors. Please CALL US for price & availability.

OMC APPLICATION GUIDE
HP	MODEL	YEAR	CYL	POWER PACK & RPM LIMIT	STATOR	RECTIFIER/ REGULATOR	TRIGGER (TIMER BASE)	IGNITION COIL
88	-	87	4	113-3110 CD4 No Limit	173-3672	153-3408	133-3379	183-2508
88	-	88	4	113-3101 CD4 6700	173-3536	153-3408	133-3379	183-2508
88	w/o Trim	89-91	4	113-4028 CD4/8 No Limit	173-3536	153-3408	133-3379	183-2508
88	with Trim	89-91	4	113-4028 CD4/8 No Limit	173-3536	193-4204	133-3379	183-2508
88	-	92-93	4	113-4028 CD4/8 No Limit	173-3536	153-3408	133-3379	183-2508
88	w/o Trim	94	4	113-4030 CD4/8 5800	173-3536	153-3408	133-3379	183-2508
88	with Trim	94	4	113-4030 CD4/8 5800	173-3536	193-4204	133-3379	183-2508
88	TS 20 Inch	94-95	4	113-4028 CD4/8 No Limit	173-3536	153-3408	133-3379	183-2508
88	TS 25 Inch	94-95	4	113-4028 CD4/8 No Limit	173-3536	193-4204	133-3379	183-2508
88	MS	95-96	4	113-4028 CD4/8 No Limit	173-3536	153-3408	133-3379	183-2508
88	TS 20 Inch	96	4	113-4028 CD4/8 No Limit	173-3536	153-3408	133-3379	183-2508
88	TS 25 Inch	96	4	113-4028 CD4/8 No Limit	173-3536	193-4204	133-3379	183-2508
HP	MODEL	YEAR	CYL	POWER PACK & RPM LIMIT	STATOR	RECTIFIER/ REGULATOR	TRIGGER (TIMER BASE)	IGNITION COIL
90	6 Amp	81-84	4	113-2125 CD4 No Limit	173-3672	153-3408	133-3376	183-2366
90	10 Amp	81-84	4	113-2125 CD4 No Limit	173-3672	193-5204	133-3376	183-2366
90	w/o Trim	85	4	18-5783 CD4 No Limit	173-3672	153-3408	133-3376	183-2508
90	with Trim	85	4	18-5783 CD4 No Limit	173-3672	193-5204	133-3376	183-2508
90	w/o Trim	86-87	4	113-3110 CD4 No Limit	173-3672	153-3408	133-3376	183-2508
90	with Trim	86-87	4	113-3110 CD4 No Limit	173-3672	193-5204	133-3376	183-2508
90	-	88	4	113-3101 CD4 6700	173-3536	153-3408	133-3379	183-2508
90	w/o Trim	89-90	4	113-4028 CD4/8 No Limit	173-3536	153-3408	133-3379	183-2508
90	with Trim	89-90	4	113-4028 CD4/8 No Limit	173-3536	193-4204	133-3379	183-2508
90	-	91	4	113-4028 CD4/8 No Limit	173-3536	193-4204	133-3379	183-2508
HP	MODEL	YEAR	CYL	POWER PACK & RPM LIMIT	STATOR	RECTIFIER/ REGULATOR	TRIGGER (TIMER BASE)	IGNITION COIL
90	-	92-93	4	113-4028 CD4/8 No Limit	173-3536	193-4204	133-3379	183-2508
90	w/o Trim	94	4	113-4030 CD4/8 5800	173-3536	153-3408	133-3379	18-5179
90	w/Trim	94	4	113-4030 CD4/8 5800	173-3536	193-4204	133-3379	18-5179
90	JE Turbojet	94	4	113-4030 CD4/8 5800	173-3536	193-4204	133-3379	18-5179
90	JLE	95	4	113-4028 CD4/8 No Limit	173-3536	193-4204	133-3379	18-5179
90	Turbojet	95	4	113-4030 CD4/8 5800	173-3536	193-4204	133-3379	18-5179
90	EL, EX, SL 60°	95	4	*113-6292 OPTICAL	173-4849	193-6048	133-6343	3740
HP	MODEL	YEAR	CYL	POWER PACK & RPM LIMIT	STATOR	RECTIFIER/ REGULATOR	TRIGGER (TIMER BASE)	IGNITION COIL
90	20 Inch	96-97	4	113-4028 CD4/8 No Limit	173-3536	153-3408	133-3379	18-5179
90	25 Inch	96-97	4	113-4028 CD4/8 No Limit	173-3536	193-4204	133-3379	18-5179
90	60°	96-05	4	113-6292 OPTICAL	173-4849	193-6048	133-6343	3740
100	-	65-66	4	N/A	N/A	193-0076	POINTS	N/A
100	Starflite	67	4	113-8362 BATTERY CD	R580648	153-3408	R580668	183-2382
100	Starflite	68	4	113-8362 BATTERY CD	173-0725	153-3408	133-5008	183-2382
100	-	71	4	113-7123 BATTERY CD	173-0744	153-3408	POINTS	183-2382
100	-	72	4	113-8362 BATTERY CD	173-0744	153-3408	133-5008	183-2382
100	ALL Recreational	80	4	113-2125 CD4 No Limit	173-3672	173640 OEM Only	133-3376	18-5176
HP	MODEL	YEAR	CYL	POWER PACK & RPM LIMIT	STATOR	RECTIFIER/ REGULATOR	TRIGGER (TIMER BASE)	IGNITION COIL
100	ALL Recreational	88	4	113-3101 CD4 6700	173-3536	193-4204	133-3379	18-5176
100	ALL Recreational	89	4	113-4028 CD4/8 No Limit	173-3536	193-4204	133-3379	18-5179
100	Recreational w/o Trim	90	4	113-4028 CD4/8 No Limit	173-3536	153-3408	133-3379	18-5179
100	Recreational with Trim	90	4	113-4028 CD4/8 No Limit	173-3536	193-4204	133-3379	18-5179
100	Recreational	91	4	113-4028 CD4/8 No Limit	173-3536	153-3408	133-3379	18-5179
100	Recreational w/o Trim	92-93	4	113-4028 CD4/8 No Limit	173-3536	153-3408	133-3379	18-5179
100	Recreational w/o Trim	94	4	113-4030 CD4/8 5800	173-3536	153-3408	133-3379	18-5179
100	Recreational with Trim	94	4	113-4030 CD4/8 5800	173-3536	193-4204	133-3379	18-5179
100	Commercial	84	4	113-2684 CD4 5700	173-3672	193-5204	133-3376	18-5176
100	Commercial	85	4	18-5783 CD4 No Limit	173-3672	193-5204	133-3376	18-5179
HP	MODEL	YEAR	CYL	POWER PACK & RPM LIMIT	STATOR	RECTIFIER/ REGULATOR	TRIGGER (TIMER BASE)	IGNITION COIL
100	Commercial	86	4	113-3116 CD4 5700	173-3672	193-5204	133-3376	18-5179
100	Commercial	87	4	113-3116 CD4 5700	173-3672	153-3408	133-3376	18-5179
100	Commercial	88	4	113-3101 CD4 6700	173-3536	193-4204	133-3379	18-5179
100	Commercial	89	4	113-4030 CD4/8 5800	173-3536	193-4204	133-3379	18-5179
100	Commercial w/o Trim	90	4	113-4030 CD4/8 5800	173-3536	153-3408	133-3379	18-5179
100	Commercial with Trim	90	4	113-4030 CD4/8 5800	173-3536	193-4204	133-3379	18-5179
100	Commercial	91	4	113-4030 CD4/8 5800	173-3536	193-4204	133-3379	18-5179
100	Commercial	92-93	4	113-4030 CD4/8 5800	173-3536	193-4204	133-3379	18-5179
100	Commercial	94	4	113-4030 CD4/8 5800	173-3536	193-4204	133-3379	18-5179
100	Commercial	95	4	113-4030 CD4/8 5800	173-3536	193-4204	133-3379	18-5179

CDI ELECTRONICS IGNITION COMPONENTS
DESCRIPTION	PART #	PRICE	SELECT
POWERPACK	113-2125 Click Image For Larger	Bombardier Price $111.00 OUR PRICE $99.00
POWERPACK	18-5759 Click Image For Larger	Bombardier Price $111.00 OUR PRICE $87.50
POWERPACK	18-5783 Click Image For Larger	Bombardier Price $142.18 OUR PRICE $129.00
POWERPACK	113-3101 Click Image For Larger	Bombardier Price $168.96 OUR PRICE $130.50
POWERPACK	113-3110 Click Image For Larger	Bombardier Price $139.96 OUR PRICE $121.50
POWERPACK	113-3116 Click Image For Larger	Bombardier No Longer Makes This OUR PRICE $131.50
POWERPACK	113-4028 Click Image For Larger	Bombardier Price $140.96 OUR PRICE $122.50
POWERPACK	113-4030 Click Image For Larger	Bombardier Price $161.96 OUR PRICE $144.00
POWERPACK	113-6292 Click Image For Larger	Bombardier Price $295.96 OUR PRICE $264.25
POWERPACK Same as above, but kit with wires	6292K1 Click Image For Larger	Bombardier Does Not Make A Kit OUR PRICE $266.50
POWERPACK	113-7123 Click Image For Larger	Bombardier Price $377.40 OUR PRICE $310.00
POWERPACK & COIL KIT Replaces and upgrades old-style battery CD components (Prestolite ignitions)	113-8362 Click Image For Larger	Bombardier Price $438.96 OUR PRICE $423.00
STATOR	173-0725 Click Image For Larger	Bombardier No Longer Makes This OUR PRICE $224.00
STATOR	173-0744 Click Image For Larger	Bombardier No Longer Makes This OUR PRICE $224.50
STATOR	173-3536 Click Image For Larger	Bombardier Price $275.80 OUR PRICE $236.75
STATOR	173-3672 Click Image For Larger	Bombardier Price $265.80 OUR PRICE $237.50
STATOR	173-4849 Click Image For Larger	Bombardier Price $373.30 OUR PRICE $312.50
STATOR	R580648 REPAIR & RETURN ONLY Click Image For Larger	$178.50
STATOR	R580650 REPAIR & RETURN ONLY	$153.00
STATOR	R580668 REPAIR & RETURN ONLY	$228.00
RECTIFIER	153-3408 Click Image For Larger	Bombardier Price $49.96 OUR PRICE $41.00
REGULATOR	193-0076 Click Image For Larger	Bombardier No Longer Makes This OUR PRICE $227.00
RECTIFIER- REGULATOR	193-4204 Click Image For Larger	Bombardier Price $108.95 OUR PRICE $98.00
RECTIFIER- REGULATOR	193-5204 Click Image For Larger	Bombardier Price $295.96 OUR PRICE $261.00
RECTIFIER- REGULATOR	193-6048 Click Image For Larger	Bombardier Price $246.63 OUR PRICE $229.00
REGULATOR	173640 OEM ONLY Click Image For Larger	$182.00
TIMER BASE	133-3376 Click Image For Larger	Bombardier Price $281.63 OUR PRICE $234.00
TIMER BASE	133-3379 Click Image For Larger	Bombardier Price $251.63 OUR PRICE $215.00
SENSOR	133-5008 Click Image For Larger	Bombardier No Longer Makes This OUR PRICE $236.00
OPTICAL SENSOR	133-6343 Click Image For Larger	Bombardier Price $76.63 OUR PRICE $65.00
IGNITION COIL	18-5176 Click Image For Larger	Bombardier Price $47.96 OUR PRICE $35.00
IGNITION COIL	183-2382 Click Image For Larger	Bombardier Price $51.96 OUR PRICE $49.00
IGNITION COIL	18-5179 Click Image For Larger	Bombardier Price $34.00 OUR PRICE $26.00
IGNITION COIL	3740 Click Image For Larger	Bombardier Price $47.00 OUR PRICE $36.00
V4, V6, V8 Magnet Kit for 35 AMP Alternators. Includes magnet, epoxy kit REPLACES ONE MAGNET WILL NOT FIT 60° MOTORS!!!	Click for Larger Image	$26.00 Per Magnet
